Antenna Research Lab

This research group utilizes the facilities available in the Antenna Research Lab at the University of Jordan to fabricate and conduct measurements on the designed antenna and microwave circuits.

In addition, this group has collaboration with other universities based on the research type, such as:

University of Glasgow

Universidad Carlos III de Madrid

Universiti Kebangsaan Malaysia

The antenna research lab has currently the following equipments:

Protomat LPKF S62 CNC machine:

Vector network analyzer (ZNB8):

Spectrum analyzer:

Antenna radiation pattern measurement setup:

Anechoic chamber: Under construction

Dremel Drill Press Rotary Tool Workstation:

The Dremel Rotary Tool Workstation gives you a drill press, tool holder, and flex shaft holder all in one convenient location. Use it to drill accurate perpendicular and angled holes. Use it to hold tools in place for applications such as sanding and buffing. The telescoping flex shaft holder extends to any height from 16 to 29 in.

Articulating drill press to drill perpendicular and angled holes in 15-degree increments, up to 90 degrees horizontal.

Tool holder to hold tools at 90 degrees horizontal for tasks such as polishing metal objects, sanding different shapes, and grinding metal pieces.

Flex shaft tool stand to allow telescopic adjustment to any height between 16 and 29 in.

Crow's nest for onboard storage for drill bits, wrenches, and other accessories.

Cord management clips for safe storage of power cords.

Inch and metric marking on base for accurate drilling of your workpiece.

Sturdy metal base with four clamping points to securely hold your workpiece.

Includes the workstation attachment, mounting wrench, and instructions for use.

Product Depth (in.): 7.7

Product Height (in.): 14

ANSYS 2024R1 Software:

The Ansys Electronics Desktop (AEDT) is a platform that enables true electronics system design. AEDT provides access to the Ansys gold-standard electromagnetics simulation solutions such as Ansys HFSS, Ansys Maxwell, Ansys Q3D Extractor, Ansys SIwave, and Ansys Icepak using electrical CAD (ECAD) and mechanical CAD (MCAD) workflows. In addition, it also includes direct links to the complete Ansys portfolio of thermal, fluid, and mechanical solvers for comprehensive multiphysics analysis. Tight integration among these solutions provides the user with unprecedented ease of use for setup and faster resolution of complex simulations for design and optimization.
